MONORAIL BM Profile linear ball guides

BM ball guideways are reliable components for the entire range of industrial applications

BM ball guideways are reliable components for the entire range of industrial applications

Request for quote SINGAPUR

To receive a quote please fill in this form below. One of our sales representatives is glad to help you.

MONORAIL BM

Profiled guideway Monorail BM Balls
Profiled guideway Monorail BM Balls

SCHNEEBERGER's MONORAIL BM linear ball guides features excellent dynamic properties and many commercial benefits. Designed with a small number of cleverly arranged components, it provides for excellent running properties due to the small number of transitions in the ball tracks, which lead to very quiet running, low pulsation and low friction as well as high travel speeds. The use of a trapezoidal rail section results in an extremely rigid guideway coupled with a substantial reduction in servicing time as additional wipers can be changed without dismantling the carriage. Complete sealing of the carriage guarantees maximum reliability coupled with a long service life. This robust and economical guideway rounds off SCHNEEBERGER's range of products for industrial applications with high demands on speed, reliability and consistant running properties.

Stainless steel version

Linear ball guides made of stainless steel SCHNEEBERGER MONORAIL BM WR/SR stainless steel guideways are designed for applications where common anticorrosion coatings are not sufficient. This is the case if linear guides are used in an environment conducive to corrosion and in processes which cannot tolerate particle generation from anticorrosion coatings.

Ball MONORAIL BM WR / BM SR Stainless Steel Version »

SCHNEEBERGER E-SHOP

SCHNEEBERGER MONORAIL and MINIRAIL profile guideways - limited quantity, easy ordering, quick delivery

New carriage types expand the range of applications

MONORAIL BM
MONORAIL BM

New carriage types expand the SCHNEEBERGER MONORAIL BM series.

The MONORAIL BM profile rail guideways have been an important component of the SCHNEEBGERGER product range for many years. Now the product range has nearly doubled by the addition of new BM carriage types, featuring low and short versions. This opens up numerous new areas of application. See the expanded product range under the product overview "Carriages"

More information:

Link to press release

Product overview BM carriages

Technical data and options

Dimensions and capacities
Links to the following sizes:

MONORAIL BM 15 Profile linear balls guideways
MONORAIL BM 20 Profile linear balls guideways
MONORAIL BM 25 Profile linear balls guideways
MONORAIL BM 30 Profile linear balls guideways
MONORAIL BM 35 Profile linear balls guideways
MONORAIL BM 45 Profile linear balls guideways

Very good dynamic characteristics and superb economy are the distinguishing features of the MONORAIL BM ball guideway. Thanks to the small number of transitions in the ball tracks, this novel design with its low number of optimally designed components provides outstanding running characteristics, which are distinguished by smooth running, low pulsation, reduced friction values and high travelling speeds.

Product overview of MONORAIL carriages with balls

Product overview BM rails

Technical data and options

Dimensions and capacities
Links to the following sizes:

MONORAIL BM 15 Profile linear balls guideways
MONORAIL BM 20 Profile linear balls guideways
MONORAIL BM 25 Profile linear balls guideways
MONORAIL BM 30 Profile linear balls guideways
MONORAIL BM 35 Profile linear balls guideways
MONORAIL BM 45 Profile linear balls guideways

The trapezoidal rail section guideway results in a highly rigid guideway and also substantially reduces the amount of maintenance required since parts subject to wear can be replaced without the need to dismantle the guideway. Complete sealing of the carriages is a guarantee of unparalleled reliability matched by a long service life. This robust and versatile guideway thus ideally complements the MONORAIL MR roller guideway.

Product overview of MONORAIL rails with balls

Downloads

MONORAIL AMSABS 3L - Product brochure
MONORAIL AMSABS 3L - Product brochure Profile linear guideways with absolute measuring system for long axesDownload now
MONORAIL and AMS - Product catalog
MONORAIL and AMS - Product catalog Profile guideways and integrated measuring systemsDownload now
MONORAIL and AMS - Application catalog
MONORAIL and AMS - Application catalog Lubrifiaction, dimensioning, installation, mounting, measure of precautionDownload now
MONORAIL and AMS Mounting instruction
MONORAIL and AMS Mounting instruction Profile guideways and integrated measuring systemsDownload now
RoHS & REACH - Compliance
RoHS & REACH - Compliance SCHNEEBERGER GmbH, Directive 2011/65/EU, Regulation (EC) No 1907/2006, in EnglishDownload now
MONORAIL MR4S - Spare parts and Modification instruction
MONORAIL MR4S - Spare parts and Modification instruction MONORAIL MR4S - Spare parts and Modification instructionDownload now
Mounting notes MONORAIL MR4S
Mounting notes MONORAIL MR4S Mounting notes MONORAIL - Carriages MR4SDownload now
Blue Competence Fyler
Blue Competence Fyler Substainability that pays off.Download now

MONORAIL movie

Significant customer benefits of MONORAIL: simple, versatile lubricating options and guide rails up to 6 meters in length – reduced number of butt joints and resulting installation costs.

SCHNEEBERGER overview MONORAIL and AMS

Assembly instructions for SCHNEEBERGER MONORAIL carriages

Press releases

High precision with MONORAIL BM
High precision with MONORAIL BM Inkjet machine with high precision SCHNEEBERGER profile linear ball guides.Download now
New carriage types expand the range of applications
New carriage types expand the range of applications The Monorail BM profile rail guideways have been an important component of the Schneeberger product range for many years.Download now

Service Life Calculation for SCHNEEBERGER MONORAIL Guideways

Calculation exclusively for horizontal configuration of an axle with 2 rails and 4 carriages. The coordinate origin is in the centre between the carriages at rail screw-on Level.

Service Life Calculation

CAD data for type BM (with balls) for download:

The selected size can be configured and is available in all common data formats Please click on the appropriate size combination to start downloading.

By clicking on the following link you will be automatically redirected to CADENAS.

Open CAD data
Open Productfinder

Advantages

  • High rigidity and high load-bearing capacities in all directions
  • Quite, smooth running with diminished pulsation and low friction
  • Speed up to 5 m/s and acceleration up to 100 m/s²
  • Great variety of carriage and rail types for a broad range of applications
  • Four different accuracy classes - Four different preload classes
  • Carriage and rail types for attachment from above and from below
  • Single piece rail length up to 6 m
  • Long service life-easy and cost-saving maintenance
  • Wide scope of accessoires and options
  • Different coatings for corrosion protection
  • Integrated length measuring system available
  • Integrated rack as an option

Features

  • O-geometry
  • 2-point contact
  • Optimized runway geometry
  • Trapezoidal rail profile
  • Complete sealing
  • Versatile lubrication possibilities
  • Through-hardened carriages
  • Exchangeability
