SCHNEEBERGER Ball screws SBS

SCHNEEBERGER ball screws complete our product portfolio

Our ground positioning ball screws are mainly used in highly demanding applications such as machine tool or measuring
and testing machines. The precision ground ball contact surfaces deliver high positioning and repeat accuracy. This means,
the path distance can be measured via the spindle. Furthermore these ball screws operate smoothly and hold constant
torque.

    SCHNEEBERGER Ball screw SBS
    SCHNEEBERGER Ball screw SBS

    The precision-ground ball contact surfaces enable high positioning and repeat accuracy. Furthermore, a smooth, constant-torque running behavior is convincing. Interesting for demanding applications in machine tools as well as measuring and testing technology.

    • Spindle and nut are precision ground
    • Low no-load torque
    • Price-performance optimized

    Availability of the SCHNEEBERGER ball screw (SBS)

    SBSDouble nut
    Pitch51015202530
    ∅32
    ∅40
    ∅50
    ∅63
    SBSSingle nut
    Pitch51015202530
    ∅32
    ∅40
    ∅50
    Performance parameterDouble nut (DSF)Single nut (ESF)
    Spindle diameter in mmØ 32…, Ø 40…, Ø 50…, Ø 63…
    Max. thread length in mm2‘000
    ISO accuracy class, type PIT 3 (V 300p: 12 µm)
    Max. speed in m/min.10065
    Max. acceleration in m/s215 (1,5g)6 (0,6g)
    Nut preload2-point (7 % Cdyn)4-point (5 % Cdyn)



    Downloads

    Ball Screws - Product catalog
    Ball Screws - Product catalog Precision groundDownload now

    Press releases

    Press release SCHNEEBERGER “SBS ball screws”
    Press release SCHNEEBERGER “SBS ball screws” The new Schneeberger ball screws (SBS) are impressive due to their precision and efficiency, which the ground and hardened ball contact surfaces are primarily responsible for. Download now

    Areas of application for ground ball screws

    • Machine tools
    • Process machines
    • General mechanical engineering
    • Robotics and automation
    • Drive technology
    • Plastic injection molding machines
    • Measuring and testing technology
